MBRP Exhaust Installation Guide: Step-by-Step for Your Truck or Jeep in Charlotte

MBRP exhaust systems are available at DIY Customs Store. We ship to all 50 states. Free shipping applies to orders over $200. This guide provides technical instructions for installing an MBRP cat-back or axle-back system on trucks and Jeeps.

Required Tools and Equipment

Proper installation requires specific mechanical tools. Gather all items before starting the procedure.

• Socket Set: 13mm, 14mm, 15mm, and 17mm sockets.
• Wrenches: Matching metric sizes for tight clearance areas.
• Exhaust Hanger Pliers: For removing rubber isolators.
• Penetrating Lubricant: PB Blaster or WD-40 for seized fasteners.
• Reciprocating Saw: For wheelbase-specific pipe trimming.
• Measuring Tape: To confirm cut lengths.
• Safety Gear: Jack stands, wheel chocks, gloves, and eye protection.
• Torque Wrench: For final clamp tightening.

Technical Preparation

1. Place the vehicle on a flat surface.
2. Engage the parking brake and use wheel chocks.
3. Allow the exhaust system to cool completely.
4. Apply penetrating lubricant to all factory bolts and rubber hangers.
5. Identify the MBRP part number and verify all components against the packing list.
6. Consult the specific vehicle wheelbase to determine if front pipe trimming is necessary.

Step 1: Removal of Factory Exhaust

Removal procedures vary by vehicle make and model. Most truck and Jeep systems use a combination of clamps and rubber hangers.

1. Disconnect Front Joint: Loosen the band clamp or remove the flange bolts behind the catalytic converter. Retain factory hardware if the MBRP kit requires reuse.
2. Separate Components: If the system is a single welded unit, use a saw to cut the pipe behind the muffler. This allows for easier removal over the rear axle.
3. Detach Hangers: Use exhaust hanger pliers to push the metal rods out of the rubber isolators. Work from the front of the vehicle to the rear.
4. Clear the Axle: Rotate the tailpipe section to navigate it over the rear axle assembly. Remove the factory system from the workspace.

Step 2: MBRP Component Fitting

MBRP systems utilize slip-fit connections and band clamps.

1. Front Pipe Installation: Attach the front pipe to the factory connection. If a wheelbase extension pipe is included, measure and cut it according to the MBRP instruction sheet.
2. Muffler Placement: Slide the muffler inlet onto the front pipe. Insert the muffler hanger rods into the existing factory rubber isolators.
3. Over-Axle Pipe: Route the over-axle pipe over the rear suspension. Connect the inlet to the muffler outlet.
4. Tailpipe Connection: Attach the tailpipe to the over-axle section. Ensure the rear hanger rod is secured in the factory rubber mount.

Step 3: Alignment and Clearance

Proper alignment prevents vibrations and heat damage.

1. Position Clamps: Place band clamps over every slip joint. Do not tighten yet.
2. Check Clearances: Ensure a minimum of 1-inch clearance between the exhaust and brake lines, fuel lines, wiring harnesses, and suspension components.
3. Level the System: Adjust the rotation of the pipes to ensure the muffler and tailpipe are level.
4. Tip Installation: Slide the MBRP exhaust tip onto the tailpipe. Position the tip to exit at the desired depth and angle.

Step 4: Final Tightening and Inspection

1. Start at the Front: Begin tightening clamps at the front connection point. Proceed rearward to the tailpipe.
2. Torque Specifications: Tighten 2.5-inch and 3-inch band clamps to approximately 45-60 ft-lbs.
3. Security Check: Vigorously shake the exhaust system. There should be no contact with the vehicle chassis or components.
4. Clean the Tip: Use a cloth to remove oils and fingerprints from the exhaust tip. This prevents permanent staining during the first heat cycle.

Step 5: Initial Sound Check

1. Start the engine.
2. Listen for exhaust leaks at all joint locations.
3. Look for condensation or smoke escaping from clamps.
4. If a leak is detected, stop the engine and readjust the clamp positioning.

MBRP Exhaust Systems: Pros and Cons

Pros

• Installation: Bolt-on design requires no welding for most applications.
• Material Options: Choice of Aluminized Steel (Armor Lite), T409 Stainless (Armor Plus), or T304 Stainless (Armor Pro).
• Sound Profile: Engineered to provide a deeper tone than factory systems.
• Efficiency: High-flow designs reduce backpressure.

Cons

• Drone: Certain configurations may produce interior cabin noise at cruising speeds.
• Rust Risk: Aluminized steel options are not recommended for high-salt environments.
• Installation Complexity: Rusty factory hardware on older vehicles may require professional assistance.

Professional Support and Availability

DIY Customs Store provides nationwide shipping to all 50 states. We utilize a network of 25 warehouses across America to ensure rapid delivery.

For residents in Charlotte, North Carolina, and surrounding areas, our online platform offers the full MBRP catalog with competitive pricing. Orders over $200 qualify for free shipping. While our headquarters and local pickup option are located in Pittsburgh, we serve automotive enthusiasts nationwide through our e-commerce site at diycustoms.store.

If technical difficulties arise during installation, consult an MECP certified professional. MECP certification ensures the technician has the required knowledge for complex automotive electronics and mechanical integrations.

Outlet and Clearance Options

Significant discounts are available in our outlet section. This category includes scratched, dented, used, or end-of-life products. Brands often found in this section include Linkswell, Fusion, Hertz, and Wet Sounds.

Visit the outlet here: DIY Customs Store Outlet Clearance.

Summary of National Services

• Shipping: All 50 states.
• Free Shipping: Available on orders over $200.
• Inventory: 25 warehouses nationwide.
• Ordering: Online at diycustoms.store.
• Local Pickup: Pittsburgh headquarters.

MBRP exhaust kits provide a functional upgrade for truck and Jeep owners in Charlotte and across America. Follow all safety protocols and vehicle-specific instructions for optimal performance.

---
