Audio Control lc5i pro 5 channel line out converter with accubass®
Upgrade your vehicle's integration infrastructure with the specialized precision engineering of AudioControl. Designed by audiophiles for installers, this high-performance audio component bridges the gap between your factory source unit and high-power aftermarket equipment for an optimal listening experience.
Product Overview & Core Highlights:
Audio Control lc5i pro 5 channel line out converter with accubass®
5 channel line out converter with accubass®
AudioControl brings you our most advanced line of LOCs yet. OEM integration has never been easier with the host of intelligent built-in features like LMC™ (Load Matching Circuit), allowing even the most finicky factory sound systems to no longer be an obstacle to great sound. Installer-friendly trigger modes offer flexibility and an expedited installation time since the units can be turned on via GTO™ Signal Sense (DC offset), audio signal sensing, or standard remote 12 volt input. All PRO series products feature AudioContol’s patented AccuBASS® for restoring low frequency output diminished by factory processing, and an ACR-1 level control is included to dial in the perfect level for your subwoofer right from the comfort of the driver’s seat. The Pro series ensures that you will start with the clean, powerful signal you need to take your system from sounding good to sounding great.
features
- Four channels of active speaker-level inputs (up to 40V input handling)
- Fixed and variable outputs with discrete-level controls
- AccuBASS® processing for correction of bass roll-off
- Load Selection Switch
- GTOTM Signal Sensing
- Ground Isolation Switch
- ACR-1 dash remote included
- Compact design
🚨 Critical Performance Specifications:
- Product Integration Core: Active OEM Speaker-Level Line Output Converter (LOC) & Line Driver
- Input Signal Capacity Layout: 2-Channel / 4-Channel High-Power Speaker-Level Inputs (Up to 40 Volts RMS / 400W continuous)
- Pre-Amp Output Configuration: 5-Channel RCA Output channels (Delivers up to 9.5V RMS Peak output voltage)
- Bass Integration Protection: Yes (Patented AccuBASS® Bass Roll-Off Compensation Circuitry)
- Switchable Internal Load Selection Switch: 20 Ohms, 60 Ohms, or 20k Ohms (Bypasses factory smart-radio muting faults)
- Automated Turn-on Trigger Options: GTO™ Signal Sense (DC Offset), Audio Sense, or 12V Remote Wire Lead
- Frequency Response Response: 10Hz – 22kHz (+/- 1dB)
- Total Harmonic Distortion (THD): <0.01% for clean, uncolored factory radio integration
- Signal-to-Noise Ratio (SNR): >110dB (Ultra-low noise background floor layout)
- Total Package Boxed Shipping Weight: 5.0 lbs
