AEM X-Series 0-15 psi Digital Pressure Gauge Kit, Black Bezel, Reversible Faceplate - 30-0309

X-Series Digital Gauges include new technological features that make them easier to use. Two buttons on the faceplate deliver programmability for peak/recall, standard or metric center LED readout and sweeping LED needle, and user-selectable threshold warnings. The gauges are AEMnet CAN-bus enabled, so they can be daisy chained together for use with the Infinity ECU, Series 2 EMS, AQ-1 Data Logger, or 3rd party EMS or logger that accepts AEMnet. 0-5V analog outputs are also included for inputting into data loggers and engine management systems. X-Series Pressure Gauge 0-15psi, Black Bezel and Reversible Black Boost or Fuel Pressure Faceplate

• Slim 0.825" overall gauge depth and 0.200" cup depth - mount them virtually anywhere!
• Optional silver bezel with white faceplate accessory kit available (sold separately)
• AEMnet CANbus-enabled for transmitting data to EMS or Data Logger
• 0-5v analog outputs for transmitting data to EMS or Data Logger
• 2-1/16th (52mm) gauge diameter for easy mounting in gauge pods
• 24 green outer LEDs for quick reference to engine parameter
• Positive locking connectors provide secure connection
• Auto dimming sensor delivers ideal display brightness
• Center LED is 87% larger than original AEM gauges
• Peak/Recall via gauge face buttons
• User selectable threshold warnings

The AEM X-Series Pressure Gauge Kit provides precise 0-15 psi pressure monitoring in a compact, easy-to-install design. Part number 30-0309 features a black bezel and reversible black boost or fuel pressure faceplate, allowing the gauge to complement a range of vehicle interiors and engine-monitoring setups. Its digital display combines a sweeping LED needle with a center LED readout for fast, easy-to-read pressure information.

Two faceplate buttons provide access to peak and recall functions, selectable standard or metric center LED readouts, and user-configurable threshold warnings. An automatic dimming sensor adjusts display brightness for improved visibility in changing light conditions, while 24 green outer LEDs provide quick reference to the monitored engine parameter. The slim housing and shallow cup design support flexible mounting in standard gauge pods and other custom locations.

The AEM X-Series gauge is AEMnet CAN-bus enabled, allowing it to be daisy chained with compatible AEM Infinity ECUs, Series 2 EMS units, AQ-1 Data Loggers, and third-party systems that accept AEMnet. Integrated 0-5 volt analog outputs provide additional connectivity to data loggers and engine management systems. Positive-locking connectors help maintain secure electrical connections during vehicle operation. A silver bezel with white faceplate accessory kit is available separately.

What's Included

• AEM X-Series 0-15 psi digital pressure gauge
• Black bezel
• Reversible black boost or fuel pressure faceplate
• Gauge wiring and connectors

Fitment

Universal automotive fitment for applications requiring 0-15 psi boost or fuel pressure monitoring. The standard 2-1/16-inch gauge format is designed for use with compatible gauge pods and mounting systems. Verify sensor, wiring, and vehicle-specific installation requirements before installation.

Features:

• Compact design: Slim 0.825-inch overall gauge depth and 0.200-inch cup depth support flexible mounting locations.
• AEMnet CAN-bus connectivity: Transmits gauge data to compatible AEM engine management systems, data loggers, and third-party devices.
• 0-5 volt analog outputs: Provides signal connectivity for compatible engine management systems and data logging equipment.
• Advanced display and alerts: Includes 24 green outer LEDs, an enlarged center LED, auto dimming, peak/recall functions, and user-selectable threshold warnings.

Air Freight Prohibited: false
Not Carb Approved: false
Ltl Freight Required: false
Prop 65: Y
Part Type: automotive
Epa: N/A
Carb Acknowledgement Required: false
Regular Stock: t
Units Per Sku: 1
