AEM X-Series 0-150 PSI / 0-10 BAR Digital Oil Pressure Gauge, Part Number 30-0307

AEM's 30-0307 X-Series 150 PSI/10 BAR Digital Oil Pressure gauge combines incredible looks, increased readability and a multitude of new, easy-to-use features! It is a must for users who want highly accurate oil or fuel pressure readouts in their high performance vehicle.NOTE: The 30-0307 comes with a black bezel and black oil pressure faceplate. You will need to purchase the optional 30-0307-ACC accessory kit to get the silver bezel and white oil pressure faceplate. Each faceplate is double sided with standard PSI on one side and metric BAR on the other. The calibration for standard or metric display is easily performed using the buttons on the face of the gauge.EASIER TO READVisual improvements include a bright center LED display that is 87% larger than our original digital gauges and provides better readability. A sweeping green LED "needle" lines the edge of the gauge face for quick reference. A 33% overall increase in the gauge face display makes it easier to see at a glance.EASIER TO MOUNTDespite the larger display, X-Series Gauges are contained in a standard 2-1/16th-inch (52mm) diameter housing for mounting in a standard gauge pod. Thanks to an advanced single board design, X-Series Gauges have an incredibly slim overall depth of under 0.825", with a cup depth of only 0.200." This shallow cup depth allows X-Series Digital Gauges to be mounted practically anywhere.SMARTER INTERFACEX-Series Digital Gauges include new technological features that make them easier to use. Two buttons on the faceplate deliver programmability for peak/recall, standard or metric center LED readout and sweeping LED needle, and user-selectable threshold warnings. The gauges are AEMnet CAN-bus enabled, so they can be daisy chained together for use with the Infinity ECU, Series 2 EMS, AQ-1 Data Logger, or 3rd party EMS or logger that accepts AEMnet. 0-5V analog outputs are also included for inputting into data loggers and engine management systems. X-Series Oil Pressure Gauge 0-150psi - 0-10bar, Black Bezel and Black Faceplate

• Slim 0.825" overall gauge depth and 0.200" cup depth - mount them virtually anywhere!
• Optional silver bezel and white faceplate accessory kit available (sold separately)
• AEMnet CANbus-enabled for transmitting data to EMS or Data Logger
• 0-5v analog outputs for transmitting data to EMS or Data Logger
• 2-1/16th (52mm) gauge diameter for easy mounting in gauge pods
• Programmable center LED is 87% larger than original AEM gauges
• User selectable standard or metric display (0-100 PSI/0-7 BAR)
• 24 green outer LEDs for quick reference to engine parameter
• Positive locking connectors provide secure connection
• Auto dimming sensor delivers ideal display brightness
• Peak/Recall via gauge face buttons
• User selectable threshold warnings

Brief Description: The AEM X-Series 30-0307 Digital Oil Pressure Gauge provides accurate, easy-to-read oil or fuel pressure monitoring for high-performance vehicles. It features a black bezel, black faceplate, bright center LED display, and a sweeping green LED needle for quick visual reference. The gauge supports both standard PSI and metric BAR readouts, allowing users to select the preferred display directly through the face-mounted controls.

Designed for flexible installation, the AEM X-Series gauge uses a standard 2-1/16-inch mounting diameter compatible with common gauge pods. Its slim housing and shallow cup design allow installation in locations where conventional gauges may not fit. An automatic dimming sensor adjusts display brightness, while positive-locking connectors help maintain secure electrical connections in demanding automotive environments.

The AEM 30-0307 also provides advanced data integration features. AEMnet CAN-bus connectivity allows the gauge to transmit pressure data to compatible AEM engine management systems, data loggers, and supported third-party equipment. A 0-5V analog output is included for connection to compatible data acquisition and engine management systems. Face-mounted buttons provide access to peak and recall functions, display selection, and user-configurable threshold warnings. The included black bezel and black faceplate are standard; the optional 30-0307-ACC accessory kit is required for the silver bezel and white faceplate.

What's Included: AEM X-Series digital oil pressure gauge, black bezel, black oil pressure faceplate, wiring and connectors, and installation components. A compatible pressure sensor is required for operation unless already supplied by the installation system. Verify sensor and vehicle application requirements before installation.

Features:

• Accurate Pressure Monitoring: Displays oil or fuel pressure from 0 to 150 PSI or 0 to 10 BAR.
• Enhanced Readability: Bright center LED display and 24 green outer LEDs provide clear readings and quick visual reference.
• Slim Installation Design: Standard 2-1/16-inch gauge diameter fits common gauge pods, while the shallow housing supports flexible mounting locations.
• Advanced Data Integration: AEMnet CAN-bus connectivity and a 0-5V analog output support compatible engine management systems and data loggers.

Air Freight Prohibited: false
Not Carb Approved: false
Ltl Freight Required: false
Prop 65: Y
Part Type: automotive
Epa: N/A
Carb Acknowledgement Required: false
Regular Stock: t
Units Per Sku: 1
