AEM X-Series 8-18V Volt Gauge with Black Bezel and Faceplate - 30-0303

X-Series Digital Gauges include new technological features that make them easier to use. Two buttons on the faceplate deliver programmability for peak/recall on the Volts gauge. All X-Series gauges are AEMnet CAN-bus enabled, so they can be daisy chained together for use with the Infinity ECU, Series 2 EMS, AQ-1 Data Logger, or 3rd party EMS or logger that accepts AEMnet. 0-5V analog outputs are also included for inputting into data loggers and engine management systems. X-Series Volt Gauge 8-18V, Black Bezel and Black Faceplate

• Slim 0.825" overall gauge depth and 0.200" cup depth - mount them virtually anywhere!
• Optional silver bezel with white faceplate accessory kit available (sold separately)
• AEMnet CANbus-enabled for transmitting data to EMS or Data Logger
• 0-5v analog outputs for transmitting data to EMS or Data Logger
• 2-1/16th (52mm) gauge diameter for easy mounting in gauge pods
• 24 green outer LEDs for quick reference to system voltage
• Programmable LED is 87% larger than original AEM gauges
• Positive locking connectors provide secure connection
• Auto dimming sensor delivers ideal display brightness
• Peak/Recall via gauge face buttons

The AEM X-Series 8-18V Volt Gauge provides a clear, configurable view of vehicle system voltage in a compact 2-1/16-inch format. Part number 30-0303 features a black bezel and black faceplate, 24 green outer LEDs for quick voltage reference, and a programmable LED that is 87% larger than previous AEM gauges. The result is fast, easy-to-read voltage monitoring for street, competition, and performance applications.

Designed for flexible installation, this AEM volt gauge has a slim overall profile and shallow mounting cup, allowing it to fit in a wide range of gauge pods and custom interior locations. An auto-dimming sensor adjusts display brightness for improved visibility in changing light conditions, while the two faceplate buttons provide convenient peak and recall functionality. Positive-locking connectors help maintain secure electrical connections during vehicle operation.

The X-Series gauge is AEMnet CAN bus enabled and can be daisy chained with compatible AEM systems, including the Infinity ECU, Series 2 EMS, and AQ-1 Data Logger. It can also communicate with third-party engine management systems or data loggers that accept AEMnet. A 0-5-volt analog output is included for transmitting voltage data to compatible logging and engine management equipment. The package includes one AEM X-Series volt gauge with black bezel and faceplate. A silver bezel and white faceplate accessory kit is available separately. This product is intended for automotive use and is not identified as CARB approved.

Product Specifications and Technical Data

• Brand: AEM
• Part Number: 30-0303
• Gauge Type: Digital volt gauge
• Voltage Range: 8-18 volts
• Gauge Diameter: 2-1/16 inches, also known as 52 mm
• Bezel and Faceplate: Black
• Data Communication: AEMnet CAN bus enabled
• Analog Output: 0-5 volts

What's Included

• AEM X-Series 8-18V Volt Gauge
• Black bezel and black faceplate
• Gauge wiring and positive-locking connectors

Features:

• AEMnet CAN Bus Connectivity: Daisy chain the gauge with compatible AEM ECUs, engine management systems, data loggers, or third-party equipment that accepts AEMnet.
• 0-5-Volt Analog Output: Send system-voltage data to compatible data loggers and engine management systems for monitoring and analysis.
• Programmable Peak and Recall: Use the two faceplate buttons to access peak voltage readings and recall stored values without external controls.
• Quick-Reference LED Display: Twenty-four green outer LEDs, a larger programmable LED, and an auto-dimming sensor provide clear voltage information in varying lighting conditions.

Air Freight Prohibited: false
Not Carb Approved: false
Ltl Freight Required: false
Prop 65: Y
Part Type: automotive
Epa: N/A
Carb Acknowledgement Required: false
Regular Stock: t
Units Per Sku: 1
