AEM X-Series EGT 0-1800°F Gauge with Black Bezel and Faceplate, 30-0305

X-Series Digital Gauges include new technological features that make them easier to use. Two buttons on the faceplate deliver programmability for peak/recall, standard or metric center LED readout and sweeping LED needle, and user-selectable threshold warnings. The gauges are AEMnet CAN-bus enabled, so they can be daisy chained together for use with the Infinity ECU, Series 2 EMS, AQ-1 Data Logger, or 3rd party EMS or logger that accepts AEMnet. 0-5V analog outputs are also included for inputting into data loggers and engine management systems. X-Series EGT Gauge 0-1800F - 0-1000C, Black Bezel and Black Faceplate

• Slim 0.825" overall gauge depth and 0.200" cup depth - mount them virtually anywhere!
• Optional silver bezel and white faceplate accessory kit available (sold separately)
• AEMnet CANbus-enabled for transmitting data to EMS or Data Logger
• 0-5v analog outputs for transmitting data to EMS or Data Logger
• 2-1/16th (52mm) gauge diameter for easy mounting in gauge pods
• Programmable center LED is 87% larger than original AEM gauges
• 24 green outer LEDs for quick reference to engine parameter
• Positive locking connectors provide secure connection
• Auto dimming sensor delivers ideal display brightness
• User selectable threshold warnings (excl. Volts)
• Peak/Recall via gauge face buttons
• User selectable threshold warnings

The AEM X-Series EGT Gauge, part number 30-0305, provides precise exhaust gas temperature monitoring through a high-visibility digital and LED display. Designed for performance vehicles, this 0-1800°F gauge also supports a 0-1000°C range, making it suitable for a wide variety of gasoline, diesel, turbocharged, and motorsport applications. Its black bezel and black faceplate provide a clean, understated appearance that integrates easily into most interiors and gauge pods.

Advanced display functions make the AEM X-Series EGT Gauge easy to configure and monitor while driving. Two faceplate buttons provide access to peak and recall readings, selectable standard or metric center LED readouts, a sweeping LED needle, and user-programmable threshold warnings. An auto-dimming sensor adjusts display brightness for improved readability in changing light conditions. The programmable center LED is 87% larger than previous AEM gauges, while 24 green outer LEDs provide an immediate reference to engine parameters.

The AEM 30-0305 is AEMnet CAN-bus enabled, allowing it to transmit data through a daisy-chained network to compatible AEM Infinity ECUs, Series 2 EMS units, AQ-1 Data Loggers, or other systems that accept AEMnet communications. Integrated 0-5V analog outputs provide an additional connection method for compatible engine management systems and data loggers. Positive-locking connectors help maintain secure electrical connections, and the compact gauge design allows flexible installation in a broad range of vehicle interiors.

What's Included: AEM X-Series EGT Gauge with black bezel and black faceplate, gauge wiring and connection hardware, and installation documentation. An exhaust gas temperature sensor and optional silver bezel with white faceplate accessory kit are sold separately.

Features:

• Slim installation profile allows the gauge to be mounted in a wide range of locations and gauge pods.
• AEMnet CAN-bus connectivity supports data transmission to compatible AEM engine management systems and data loggers.
• 0-5V analog outputs provide integration with compatible engine management systems and data acquisition equipment.
• Programmable display functions include peak and recall readings, selectable standard or metric readouts, LED sweep behavior, auto dimming, and user-selectable threshold warnings.
