Air Lift LoadLifter 5000 ULTIMATE Rear Air Spring Kit for 1973-1986 Chevrolet C10 Pickup, Part 88215

LoadLifter 5000 ULTIMATE adjustable air spring kits feature all of the benefits of our heaviest rated air spring with the addition of an internal jounce bumper inside the spring for the ultimate in ride comfort. An Air Lift exclusive product! Fits vehicles with in-bed hitches. Tow and haul the heaviest loads with safety and comfort with LoadLifter 5000 ULTIMATE. Works with vehicle's leaf springs to provide up to 5,000 lbs. of rear load leveling capacity and keeps the vehicle riding stable, level and comfortable whether loaded or unloaded. Fully adjustable from 5 to 100 PSI. The closed-cell urethane foam jounce bumper inside the ULTIMATE air springs provide a cushion of air that absorbs shock, eliminates harsh jarring on rough roads and protects vehicles carrying heavy loads. Never bottom out again with the ULTIMATE! LoadLifter 5000 ULTIMATE air springs are maintenance free! Safely run with zero air pressure because of the internal jounce bumper. Replaces factory jounce bumper that is sometimes removed when adding air springs. Requires no drilling into frame! Includes industry-exclusive 60 Day No Questions Money Back Guarantee! Includes the most comprehensive Lifetime Warranty in the industry---covers all kit contents including brackets, fittings and air line. Air springs are built like a tire and are reinforced by durable, 2-ply fabric for maximum strength. Exclusive upper and lower roll plates included. Protect the springs from sharp edges, such as brackets or the frame. The kit includes 2 air springs, brackets, air lines, Schrader valve and all of the hardware needed for installation. Includes fully illustrated instruction manual. Add an Air Lift on-board air compressor system to inflate and deflate air springs with the touch of a button from inside or outside of the vehicle. LoadLifter 5000 ULTIMATE with internal jounce bumper to absorb shock for best ride comfort Improves handling, braking, and steering response by maintaining ride height under load

• Up to 5,000 lbs. of load-leveling capacity (Note: Do not exceed vehicle's GVWR)
• 60 Day Industry-Exclusive No Questions Asked Money Back Guarantee
• Exclusive Internal Jounce Bumper Inside Springs Absorbs Shock
• will not fit applications with side-mount fifth wheel hitch
• Will Not Fit Applications With Side Mount Fifth Wheel Hitch
• Maintenance free! Run safely with zero air pressure.
• Maintenance Free; Run Safely w/Zero Air Pressure
• Eliminates harsh jarring on rough roads
• Up To 5000lbs Of Load Leveling Capacity
• Requires 8" between tire and frame
• Requires 8 Between Tire And Frame
• Air adjustable from 5 to 100 PSI
• Limited Lifetime Warranty

Upgrade the load-carrying performance and ride quality of your classic Chevrolet C10 pickup with the Air Lift LoadLifter 5000 ULTIMATE rear air spring kit. Designed for 1973-1986 C10 applications, this adjustable air spring system works with the vehicle’s existing leaf springs to provide up to 5,000 pounds of rear load-leveling capacity. The system helps maintain a stable, level ride while improving handling, braking, and steering response when hauling or towing. Do not exceed the vehicle’s gross vehicle weight rating.

The Air Lift LoadLifter 5000 ULTIMATE kit features an exclusive internal jounce bumper inside each air spring. This closed-cell urethane foam bumper absorbs shock, reduces harsh jarring on rough roads, and provides additional support when the springs are operated with little or no air pressure. The air springs are adjustable from 5 to 100 PSI, allowing the ride to be tailored for varying loads. Reinforced two-ply construction, upper and lower roll plates, and maintenance-free operation provide dependable performance for demanding towing and hauling conditions.

Installation requires no drilling into the frame and replaces the factory jounce bumpers that may be removed during air spring installation. The kit includes two rear air springs, mounting brackets, air lines, Schrader valve, installation hardware, and a fully illustrated instruction manual. It requires 8 inches of clearance between the tire and frame and will not fit applications equipped with a side-mount fifth-wheel hitch. Air Lift backs the kit with an industry-exclusive 60-day no-questions-asked money-back guarantee and a limited lifetime warranty covering the kit contents, including brackets, fittings, and air line. An Air Lift onboard air compressor system can be added for convenient inflation and deflation from inside or outside the vehicle.

Product Specifications and Technical Data

• Brand: Air Lift
• Product Line: LoadLifter 5000 ULTIMATE
• Part Number: 88215
• Application: Rear suspension air spring kit
• Load-Leveling Capacity: Up to 5,000 pounds
• Adjustable Pressure Range: 5 to 100 PSI
• Spring Construction: Reinforced two-ply fabric with internal jounce bumper
• Installation Requirement: No frame drilling; requires 8 inches of tire-to-frame clearance

What’s Included

• Two rear air springs
• Mounting brackets
• Air lines
• Schrader valve
• Installation hardware
• Illustrated instruction manual

Features:

• Internal Jounce Bumper: Closed-cell urethane foam bumpers absorb shock, reduce harsh impact, and provide support when operating at zero air pressure.
• Load-Leveling Capacity: Supports up to 5,000 pounds of rear load-leveling capacity to help maintain ride height under heavy loads.
• Adjustable Ride Support: Air pressure adjusts from 5 to 100 PSI for improved comfort and control while towing, hauling, or driving unloaded.
• No-Drill Installation: Vehicle-specific brackets and included hardware install without drilling into the frame, simplifying installation.

Air Freight Prohibited: false
Not Carb Approved: false
Ltl Freight Required: false
Prop 65: Y
Part Type: automotive
Epa: N/A
Carb Acknowledgement Required: false
Regular Stock: t
Units Per Sku: 1
