Audison AF C4D FORZA Series 90W x 4 RMS @4Ohms, Class D 4-Channel Car Amplifier

Audison AF C4D FORZA Series 90W x 4 RMS @4Ohms, Class D 4-Channel Car Amplifier

Experience unmatched acoustic fidelity, pristine audiophile-grade detail, and state-of-the-art Italian design with a premium car audio power amplifier from Audison. Precision-engineered to deliver continuous power distribution with absolute zero background coloration, these amplifiers feature ultra-low distortion parameters and high-current circuitry tailored to reveal every nuance of high-resolution acoustic soundstages.

Product Overview & Core Highlights:

Specifications:

• Nominal power supply voltage / fuse: 11 ÷ 15 VDC / 2 x 30A
• Pulse operating voltage: 6.5 ÷ 17.5 VDC
• Idling current: 1.3 A
• Standby current draw: 1.5 mA
• Consumption @ 14.4 VDC, Minimum load impedance (Max Musical Power): 52 A
• Remote IN: 4 ÷15 VDC (1 mA)
• Remote OUT: 6.5 ÷15 VDC (150 mA)
• ART – Automatic Remote Turn on/off from Speaker-In 1.5 VDC
• Efficiency @ rated power (RMS) @14.4 VDC, 1% THD,4Ω, All Channels: 83%
• Distortion – THD+N @ 1 KHz, 4Ω, 70% Rated Power: 0.05%
• Damping factor @ 1 kHz , 4Ω, 2 VRMS: 160
• Bandwidth @ -3 dB: 10 Hz ÷ 42 kHz
• S/N ratio (A weighted @ 1 V Input, Rated Power) Master Input: 103 dBA
• Minimum load impedance: 4 Ch: 2Ω
• 2 Ch – (Bridge 1/2; 3/4): 4Ω Output Continuous Power (RMS) @14.4 VDC, 1% THD:
  • 4Ch @ 4Ω: 90 W x 4
  • 4Ch @ 2Ω: 150 W x 4
  • 2Ch (Bridge 1/2; 3/4) @ 4Ω: 300 W x 2
• Output power @ 4Ω, 1% THD+N, 14.4 V: 160 W x 4
• SN ratio (ref. 1 W output): 80 dB
• Inputs Pre-In / Speaker-In
• Input sensitivity Pre-In  0.6 ÷ 6 VRMS
• Input sensitivity Speaker-In 2.2 ÷ 22 VRMS
• SUB remote Volume Control (optional) ±12 dB
• Ambient operating temperature range: 0 °C to 55 °C (32 °F to 131 °F)
• Max size W x H x D (mm/inch): 240 x 47 x 156 / 9.44 x 1.85 x 6.14

• Authorized Internet Dealer

🚨 Critical Performance Specifications:

• Package Quantity Configuration: Sold Individually (Includes 1 Premium Component Unit)
• Manufacturer Part Number (MPN): AF C4D
• Product Category Component: Amplifiers
• Hardware Fitment Sizing Profile: 8-Inch Layout Fitment
• System Power Metrics: 90 Watts Performance Rating
• Nominal System Stability Configuration: 4 Ohms Impedance Load
• Total Package Boxed Shipping Weight: 5.0 lbs
