Audison AV UNO VOCE Series Mono Amplifier 700W 4Ω, 1300W 2Ω, 1700W 1Ω
Audison AV UNO VOCE Series Mono Amplifier 700W 4Ω, 1300W 2Ω, 1700W 1Ω
Audison - AV UNO
Regular price
$2,299.99 USD
Regular price
$2,759.99 USD
Sale price
$2,299.99 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Audison AV UNO VOCE Series Mono Amplifier 700W 4Ω, 1300W 2Ω, 1700W 1Ω
Experience unmatched acoustic fidelity, pristine audiophile-grade detail, and state-of-the-art Italian design with a premium car audio power amplifier from Audison. Precision-engineered to deliver continuous power distribution with absolute zero background coloration, these amplifiers feature ultra-low distortion parameters and high-current circuitry tailored to reveal every nuance of high-resolution acoustic soundstages.
Product Overview & Core Highlights:
AV uno - MONO AMPLIFIER 1x1300WAV uno is an amplifier featuring an innovative circuitry called POD (Power On Demand); it provides at the final stage in AB class a dynamic power that serves as a tracker to the signal to be amplified so as to increase efficiency and reduce the temperature. AV uno allows to combine the plus points, in terms of audio quality and robustness, of the AB Class traditional amplifiers with the efficiency of the D Class amplifiers. AMP (Amplifier Management Processor) constantly checks the operating status system and communicates with the user through 4 different colored LEDs, located on the top panel; ART (Automatic Remote Turn On-Off) allows automatic turn-on/off when a remote signal isn’t available from the source. AV uno is a mono amplifier designed to drive the subwoofer but also suitable for high power Dual Mono systems.
Power Supply -
• Power supply voltage: 11 ÷ 15 VDC
• Idling current: 2.0 A
• Idling current when off: 0.02 mA
• Consumption @ 14.4 VDC (Max Musical Power): 120 A
Amplifier Stage -
• Distortion - THD (1kHz @ 4Ω): 0.04 %
• Bandwidth (-3 dB): 7 ÷ 20k Hz
• S/N ratio (A weighted @ 1V): 95 dBA
• Damping factor (1k Hz @ 4Ω): 160
• Input sensitivity: 0.3 ÷ 5 V RMS
• Input impedance: 15k Ω
• Speaker-In sensitivity: 1.4 ÷ 24 V RMS
• Speaker-In impedance: 5k Ω
• Minimum load impedance: 1Ω
🚨 Critical Performance Specifications:
- Package Quantity Configuration: Sold Individually (Includes 1 Premium Component Unit)
- Manufacturer Part Number (MPN): AV UNO
- Product Category Component: Amplifiers
- Hardware Fitment Sizing Profile: 8-Inch Layout Fitment
- System Power Metrics: 700 Watts Performance Rating
- Nominal System Stability Configuration: 4 Ohms Impedance Load
- Total Package Boxed Shipping Weight: 18.0 lbs
