Clarion #010-03047-00 Pair of 6.5-inch Marine Coaxial Speaker with 1-inch (25 mm) Silk Dome Tweeters

Clarion #010-03047-00 Pair of 6.5-inch Marine Coaxial Speaker with 1-inch (25 mm) Silk Dome Tweeters

Clarion - 010-03047-00

$179.99 USD
$215.99 USD $179.99 USD
Sale Special Order this item by Clicking the Chat Button Below
Shipping calculated at checkout.

Clarion® CMSP Marine Speakers


6.5" with White and Gray Sport Grille (CMSP-651-SWG)

PART NUMBER010-03047-00

 Pair of 6.5-inch Marine Coaxial Speaker with 1-inch (25 mm) Silk Dome Tweeters

General
Sizes 6.5"/7.7"
Color White and Metallic Gray
Physical dimensions (Diameter) 6.5": 6.90" (175 mm)
7.7": 7.7" (196 mm)
Physical dimensions (Depth) 6.5": 4.19" (106 mm)
7.7": 4.6" (117 mm)
Speaker type Coaxial
Continuous power handling (RMS) 6.5": 50W
7.7": 60W
Sensitivity (SPL @ 1 W/1 m) 6.5": 87 dB
7.7": 88 dB
Frequency response (+/- 3 dB) 6.5": 55 Hz-20 KHz
7.7": 45 Hz-20 kHz
Nominal impedance 4 Ω
Recommended amplifier power (RMS) 6.5": 30-100 W/Channel
7.7": 40-120 W/Channel
LED lighting Yes - RGB (Select sport models only)
LED supply voltage 10-14.4 VDC
LED Load Current @ 14.4 VDC (max) 140 mA (Select sport models only)
Cone material Injection-molded, mica-filled polypropylene
Tweeter type Silk Dome
Tweeter size 1" (25 mm)
Warranty 1 year

Connections
Speaker connections Spade Connectors
Flying Lead with waterproof connector 18 AWG Wire (Selected sport models only)

Mounting Dimensions
Mounting depth clearance 6.5": 2.83" (72 mm)
7.7": 3.07" (78 mm)
Frontal grille protrusion 6.5": 1.36" (35 mm)
7.7": 1.53" (39 mm)
Mounting hole 6.5": 5.00"-5.25" (127-133 mm)
7.7" 6.25" (159 mm)
Bolt hole circle 6.5": 6.14" (156 mm)
7.7": 6.92" (176 mm)
