Edelbrock 3848 Low Profile EFI Elbow 75/85/90mm Throttle Body to 4150 Flange

This Edelbrock Low Profile elbow was designed for limited hood clearance applications. This adaptor can be used with our 29085 Victor Jr LS1 but cowl trimming and an SS hood are required. The 3848 Elbow can be used in other square bore (4150 style) manifold applications as well. It can be mounted forward, backward, or sideways on any of our Victor EFI Square bore (4150) style manifolds. Because of its low profile a one inch spacer is required for small or Big Block Chevy forward mount configurations to clear the water neck. It can be used with an LS1 80 mm (must use PN 2737 adaptor) or Edelbrock PN 3869 90mm Universal, or Ford style 75mm throttle bodies. The 3848 adaptor features: Bolt pattern fits LS1, LS2 and Ford 5.0l based throttle bodies, adapts to standard (4150 style) square bore manifolds, Fits manifold either in a forwards, backward, or sideways configuration, The throttle bore center sits 7.00" forward and only 2.00" up from the manifold 4150 flange, The throttle body points downward on a 5 Deg angle. For ultra-low applications out PN 3847 elbow sits 9.00" forward and only .56" above the flange, with a 12 Deg downward throttle body angle. The Edelbrock PN 3848 EFI Elbow Low Profile Universal 75/85/90mm TB to 4150 Flange

• As-Cast Finish

The Edelbrock 3848 Low Profile EFI Elbow is designed for applications with limited hood clearance. It adapts compatible throttle bodies to standard 4150-style square-bore manifolds and can be mounted in forward, backward, or sideways configurations. The elbow has an as-cast finish and is intended for EFI applications.

The bolt pattern fits LS1, LS2, and Ford 5.0L-based throttle bodies. It can be used with an LS1 80mm throttle body when paired with Edelbrock PN 2737, an Edelbrock PN 3869 90mm universal throttle body, or Ford-style 75mm throttle bodies. When used with the Edelbrock 29085 Victor Jr LS1 manifold, cowl trimming and an SS hood are required.

The throttle bore center sits 7.00 inches forward and 2.00 inches above the manifold 4150 flange, with the throttle body directed downward at a 5-degree angle. For small-block or big-block Chevy forward-mount configurations, a 1-inch spacer is required for water-neck clearance. This product is not carburetor approved.

What's Included: Edelbrock 3848 low profile EFI elbow.

Features:

• Low-profile design: Intended for applications with limited hood clearance.
• Universal 4150 adaptation: Connects compatible 75mm, 80mm, and 90mm throttle body applications to standard square-bore manifolds.
• Flexible mounting: Can be installed in forward, backward, or sideways configurations on Edelbrock Victor EFI square-bore manifolds.
• Angled throttle-body positioning: Places the throttle bore center 7.00 inches forward and 2.00 inches above the 4150 flange, with a 5-degree downward angle.
• Throttle-body bolt pattern: Fits LS1, LS2, and Ford 5.0L-based throttle bodies.
• LS1 application support: Compatible with an LS1 80mm throttle body when used with Edelbrock PN 2737.
• 90mm and 75mm compatibility: Supports Edelbrock PN 3869 90mm universal and Ford-style 75mm throttle bodies.
• Installation clearance requirements: A 1-inch spacer is required for small-block or big-block Chevy forward-mount configurations to clear the water neck; cowl trimming and an SS hood are required with the Edelbrock 29085 Victor Jr LS1 manifold.
• Finish: As-cast finish.
• Application note: Not carburetor approved.

Air Freight Prohibited: false
Not Carb Approved: true
Carb Acknowledgement Required: true
Ltl Freight Required: false
Prop 65: Y
Part Type: automotive
Epa: N/A
Regular Stock: t
Units Per Sku: 1
