Edelbrock EDE36031 Universal EFI Fuel Sump Complete Kit

The Universal Fuel Sump Kit #36031 includes everything needed for a complete installation and is designed to provide the necessary high fuel pressure required for EFI applications in vehicles equipped with an existing low-pressure carbureted fuel system. This Universal Fuel Sump is a self-contained high-pressure fuel pump/sump unit that can be easily installed under the hood. The unique design of the Edelbrock Fuel Sump allows it to deliver constant fuel pressure with no fuel return line, external fuel pressure regulator or fuel tank modifications. The Edelbrock Universal Fuel Sump is compatible with the existing factory fuel tank and pump and is ideal for use with aftermarket EFI systems as well as many popular engine swap applications that require constant 35-90 PSI fuel pressure. This Universal Fuel Sump features a compact design that is adjustable from 35 to 90 PSI and includes a vacuum reference port. A flow rate of 67 GPH can support up to 600 HP and is a perfect choice to use with Pro-Flo 3, Pro-Flo 4 or other aftermarket EFI systems. Part #36031 is a complete kit with electrical harness, hardware, hose, filter and fittings included. Consumers who wish to utilize their own fittings and hose can save money by ordering the Universal Fuel Sump only, part #36032. Both will require the installation of a vent line from the sump overflow vent port to the fuel tank. The Edelbrock Universal EFI Fuel Sump Kit is the easiest and most affordable way to make your fuel system EFI ready. NOTE: THIS SUMP IS NOT INTENDED FOR OFF ROAD USE, ROCK CRAWLING OR APPLICATIONS WHERE VEHICLE WILL BE SUSTAINED AT INCLINE OR DECLINE ANGLES GREATER THAN 45 DEGREES FOR EXTENDED DURATIONS. Universal EFI Fuel Sump Complete Kit w/pump, tank, lines, mounting kit.

• Compact Design Is Adjustable From 35 to 90 PSI

The Edelbrock Universal EFI Fuel Sump Complete Kit, part number EDE36031, is designed to provide the high fuel pressure required for electronic fuel injection applications using an existing low-pressure carbureted fuel system. This self-contained high-pressure fuel pump and sump unit installs under the hood and is compatible with the existing factory fuel tank and pump.

The compact sump design delivers constant fuel pressure without requiring a fuel return line, external fuel pressure regulator, or fuel tank modifications. Fuel pressure is adjustable from 35 to 90 PSI, and the unit includes a vacuum reference port. With a flow rate of 67 GPH, it can support engines producing up to 600 horsepower and is suitable for use with aftermarket EFI systems, including Edelbrock Pro-Flo 3 and Pro-Flo 4 systems, as well as many engine swap applications.

This complete kit includes the electrical harness, mounting hardware, hose, filter, and fittings. Installation requires a vent line from the sump overflow vent port to the fuel tank. The sump is not intended for off-road use, rock crawling, or applications where the vehicle will remain at incline or decline angles greater than 45 degrees for extended periods. This product is not carburetor-approved.

What's Included

• Universal EFI fuel sump with pump
• Tank, lines, and mounting kit
• Electrical harness
• Hose, filter, fittings, and hardware

Features:

• High-Pressure EFI Fuel Supply: Provides the fuel pressure required for EFI applications using an existing low-pressure carbureted fuel system.
• Adjustable Fuel Pressure: Compact design is adjustable from 35 to 90 PSI.
• Returnless Fuel System Design: Operates without a fuel return line, external fuel pressure regulator, or fuel tank modifications.
• 67 GPH Flow Rate: Supports engines producing up to 600 horsepower.
• Vacuum Reference Port: Includes a vacuum reference port for the fuel system.
• Factory Tank Compatibility: Works with the existing factory fuel tank and pump.
• Complete Installation Kit: Includes the electrical harness, mounting hardware, hose, filter, and fittings.
• Application Note: Requires a vent line from the sump overflow vent port to the fuel tank and is not intended for extended operation at angles greater than 45 degrees.

Air Freight Prohibited: false
Not Carb Approved: true
Ltl Freight Required: false
Prop 65: Y
Part Type: automotive
Epa: N/A
Carb Acknowledgement Required: true
Regular Stock: t
Units Per Sku: 1
