Hertz CP 1.2k Amplifier
Hertz CP 1.2k Amplifier
Hertz - CP 1.2k
Regular price
$649.99 USD
Regular price
$715.00 USD
Sale price
$649.99 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Hertz CP 1.2k Amplifier
Step into a world of refined bass with the Hertz CENTO POWER CP 1.2K This mono amplifier is engineered for high efficiency, reaching an efficiency greater than 89% within a compact, robust aluminum diecast casing. The CP 1.2K is designed to integrate seamlessly into both traditional and modern vehicle setups, thanks to its Universal Speaker Simulator and a wide operating voltage range suitable for electric vehicles. It features advanced noise rejection capabilities to ensure crystal-clear sound quality. With adjustable input levels, a low-pass crossover filter, a bass boost, and a subsonic filter, this amplifier allows for precise customization of your sound, making it an ideal choice for those seeking powerful, immersive bass without compromise.
General Specs
| Channels | 1 |
| Amp class | D |
| POWER SUPPLY | |
| Nominal power supply voltage (fuse) | 11 ÷ 15 VDC (2 x 35 A) |
| Operating power supply voltage | 9 ÷ 18 VDC |
| Idling current | 0.85 A |
| Standby current draw | 4.5 uA |
| Consumption, MIN load impedance (Max Musical Power) | 50 A |
| Remote IN | 4 ÷ 17 VDC (1 mA) |
| ART - Automatic Remote Turn on/off from SPK-IN (BTL radio only) | 1.5 VDC |
| Efficiency | 89% |
| AMPLIFIER STAGE | |
| Distortion - THD @ 100 Hz, 70% Rated Power | 0,03 % |
| Damping factor @ 1 kHz, 1W | 140 |
| Bandwidth @ -3 dB | 10 Hz ÷ 500 Hz |
| S/N ratio (A-weighted @ 1 V Input) | 102 dBA |
| Minimum load impedance | |
| @ 1 Ch: | 2 Ω |
| Adjustable Crossovers | yes |
Output Power
| Output power (RMS) @ 1% THD: | |
| 1Ch @ 4Ω | 650 W x 1 |
| 1Ch @ 2Ω | 1200 W x 1 |
| Total Power | 1200 W |
INPUTS / FILTERS
| Inputs | Pre-In / Speaker-In |
| Pre Out | Hi-Pass 50 ÷ 250Hz @ 12 dB/Oct. |
| Pre-In sensitivity | 0.32 ÷ 8 VRMS |
| Speaker-In sensitivity | 1.6 ÷ 40 VRMS |
| Sub Ch Lo-Pass | OFF / 50 ÷ 250 Hz @ 24 dB/Oct. |
| Bass Boost 50Hz | 0 ÷ 9 dB |
| Subsonic Hi-Pass | OFF / 25 Hz @ 24 dB/Oct. |
| Sub Remote Volume Control | -20 ÷ 6 dB (Active on Rear Ch with LPF ON) |
Physical Specs
| Weight | Kg | lbs |
| 2.44 | 5.37 |
