Hertz VENEZIA V4C Ch: 4 - 3 - 2 | 760 W Amplifier
Hertz VENEZIA V4C Ch: 4 - 3 - 2 | 760 W Amplifier
Hertz -
Regular price
$699.99 USD
Regular price
$800.00 USD
Sale price
$699.99 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Hertz VENEZIA V4C Ch: 4 - 3 - 2 | 760 W
Venezia V4C compact marine amplifier features an optimized power/size ratio boosting 110 W x 4 (4Ω) and 380 W x 2 (4Ω)! Hertz Advanced Class D technology maximizes efficiency and power while minimizing heat and electromagnetic radiation - enhancing sound quality that reaches new highs with Hi-Res certification! High-powered channels with bridging capability deliver the output levels needed in the marine environment. Venezia V4C is engineered and tested for marine applications (UV, salt-fog, vibrations, high/low temperature, thermal shock) and has obtained the IPX2 certification. The Safe-Lock Input, Output, and Power connections streamline installation and enhance durability in the field. The fanless convection cooling system is integrated into the cast heat-sink chassis. The balanced fully-differential input circuitry rejects electromagnetic noise and interference. The powerful and flexible preamp filter options are far beyond most mobile amplifier capabilities. Last but not least, Venezia V4C is fully protected by short-circuit, overload, and thermal protections - with auto-resetting.
| Channels | 4 - 3 - 2 |
| POWER SUPPLY | |
| Power supply voltage | 9 ÷ 16 VDC |
| ldling current (power ON/OFF): | 1 A / 0.04 mA |
| Consumption@ 2Ω, 14.4 VDC (Max Musical Power): | 21 A |
| Remote In: | 7 ÷ 15 VDC - 1 mA |
| AMPLIFIER STAGE | |
| Distorsion - THD (100Hz @ 4Ω): | <0,06% |
| Bandwidth: | 10 ÷ 42 kHz |
| S/N Ratlo (A welghted @ 1 V): | 102 dB |
| Damping factor (100Hz @ 4Ω) | 150 |
| Pre-ln sensitivity: | 0.2 ÷ 5 VRMS |
| Load impedance (MIN) @4Ch: @3Ch: @2Ch: |
2 Ω + 2 Ω + 4 Ω 2 Ω 4 Ω |
| Weight (kg/lb): | 2.62 / 5.77 |
| Adjustable Crossovers | yes |
Output Power
| OUTPUT POWER (RMS) @ 14.4 VDC, THD 1% | |
| 4Ch | 110 W x 4 (4Ω) |
| 4Ch | 190 W x 4 (2Ω) |
| 3Ch | 110 W x 2 (4Ω) + 380 W x 1 (4Ω) |
| 3Ch | 190 W x 2 (2Ω) + 380 W x 1 (4Ω) |
| 2Ch | 380 W x 2 (4Ω) |
| Total Power | 760 W |
