JL Audio® FiX™ OEM Integration DSP Processor with 8-input and 2-output Channels
Complete your ultimate high-fidelity mobile build and protect your electrical circuitry pathways from current strain with the professional-grade audio installation accessories from JL Audio. Manufactured from high-purity conductor matrices with heavy weatherized insulation jackets, these support components lock down ultra-low resistance power delivery for maximum system reliability.
Product Overview & Core Highlights:
JL Audio® FiX™ OEM Integration DSP Processor with 8-input and 2-output Channels (FiX-82)
TURN YOUR FACTORY RADIO INTO AN AFTERMARKET DREAM
The state-of-the-art FiX digital signal processor (DSP) is engineered to deliver world-class sound from factory audio systems, without replacing the OEM source unit. FiX 82 and FiX 86 automatically correct time-delayed factory outputs prior to signal summing and EQ correction.
WORLD-CLASS SOUND FROM YOUR FACTORY RADIO
USER-ADJUSTABLE 10-BAND GRAPHIC EQUALIZERS
FiX AND SUM OEM SIGNAL
30-SECOND, SINGLE-BUTTON CALIBRATION
2 OR 6 RCA OUTPUTS
2-YEAR WARRANTY
| INPUT CHANNELS | 8 |
|---|---|
| OUTPUT CHANNELS | FiX-82: 2 FiX-86: 6 (Front/Rear/Sub Output Pairs) |
| PHYSICAL DIMENSIONS (HEIGHT) | 1.85" (47 mm) |
| PHYSICAL DIMENSIONS (WIDTH) | 4.29" (109 mm) |
| PHYSICAL DIMENSIONS (DEPTH) | 6.14" (156 mm) |
| WEIGHT |
2.58 lbs (1.17 kg) |
| POWER SUPPLY TYPE | Regulated DC-DC SMPS |
| WARRANTY | 2 years |
| OPERATING VOLTAGE | 10-16 VDC |
Audio |
|
| SIGNAL-TO-NOISE RATIO @ 4 V (RMS) | 96 dB |
|---|---|
| THD+N @ RATED POWER | 0.02% (20 Hz-20 kHz) |
| INPUT VOLTAGE RANGE | 250 mV-30 V RMS |
| MINIMUM INPUT VOLTAGE | 10 mV RMS |
| INPUT LEVEL SETTING | Fully automatic |
| ANALOG OUTPUT | Unbalanced, stereo RCA jacks |
| DIGITAL OUTPUT | FiX-82: Optical (Toslink) output (S/PDIF) |
| OUTPUT IMPEDENCE | 450 Ω |
| CURRENT CONSUMPTION (STANDBY) | <1.5 mA |
| CURRENT CONSUMPTION (IDLE) | 0.7 A |
| FUSE RATING | 1 A |
Signal Processing |
|
| AUDIO RESOLUTION | 24 bit/48 kHz |
|---|---|
| NUMBER OF EQ BANDS | 30 x 2 Channels |
| EQ RESOLUTION | 1/3 octave (25 Hz-20 kHz) |
| REMOTE LEVEL CONTROL | FiX-82: Optional (DRC-100) FiX-86: Optional (DRC-100 or DRC-200) |
| REMOTE LEVEL MODES | Master Volume Control, Handsfree Optimization, LED Status Reporting (DRC-200 adds Subwoofer Level Control) |
🚨 Critical Performance Specifications:
- Package Quantity Configuration: Sold Individually (Includes 1 Premium Component Unit)
- Manufacturer Part Number (MPN): 010-03102-00
- Product Category Component: Stereos
- Physical Hardware Sizing: 85-Inch Layout Profile
- Total Package Boxed Shipping Weight: 3.5 lbs
