KC HiLiTES Pro6 Gravity LED Single Light, 20W Driving Beam, Part KCL91303

FEATURES-Powered by Gravity LED G6 optical inserts efficient, powerful, patented -Patent-pending Infinity Ring™ system houses the Pro6 Single and mounts via an all-new, universal ball mount that is highly adjustable(Patent Pending Application 14/704,736)-Driving beam pattern gives you an exceptional balance of spread and spot lighting in one beam pattern-High output, low amperage drawLIGHT PERFORMANCE-Raw Lumens: 2,300 lm-Lux @ 10 Meters: 1,310 lx-Candela: Spot- 131,000 cd-Beam Distance (Meters): 724mSPECIFICATIONS-Wattage: 20W-LED Source: CREE XPL HD -Amp Draw: 1.63A-Voltage: 9-32V-IP Rating: IP68-Dimensions: W - 6.00" x H - 7.00" x D - 3.125"PARTS INCLUDED-(1) Pro6 Single lighting system-Mounting Hardware-Complete Plug-N-Play Wiring Harness with 30 amp LED SwitchPERFORMANCE Gravity LED OPTICSPatented Gravity LED G6 optical inserts provide exceptional efficiency and light output with a Driving beam pattern and 20 watts of powerINFINITY RING™ SYSTEMThe Infinity Ring™ system provides a race-proven housing for the Pro6 Single that is strong, durable, and gives you a unique look for your vehicleUNIVERSAL BALL MOUNT The Pro6 Single comes ready to mount to any flat mounting surface with a highly adjustable ball mount. This universal ball mount easily attaches to many vehicles, including your Jeep, Truck or UTVRACE PROVEN STRENGTH & DURABILITY Inspired by endurance racing and tested by KC athletes worldwide, the Pro6 shatters all performance benchmarks, while providing the most durable and scalable light bar design available today The Gravity LED Pro6 LED light bar is an LED off-road lighting system utilizing patented Infinity Ring(r) system featuring radius to straight adjustability, modular beam patterns, and expandable widths. FEATURES-Powered by Gravity LED G6 optical inserts – efficient; powerful; patented-Patent-pending Infinity Ring/#8482; system houses the Pro6 Single and mounts via an all-new; universal ball mount that is highly adjustable(Patent Pending Application 14/704;736)-Driving beam pattern gives you an exceptional balance of spread and spot lighting in one beam pattern-High output; low amperage drawLIGHT PERFORMANCE-Raw Lumens: 2;300 lm-Lux @ 10 Meters: 1;310 lx-Candela: Spot-131;000 cd-Beam Distance (Meters): 724mSPECIFICATIONS-Wattage: 20W-LED Source: CREE XPL HD-Amp Draw: 1.63A-Voltage: 9-32V-IP Rating: IP68-Dimensions: W-6.00in. x H-7.00in. x D-3.125in.PARTS INCLUDED-(1) Pro6 Single lighting system-Mounting Hardware-Complete Plug-N-Play Wiring Harness with 30 amp LED SwitchPERFORMANCE Gravity LED OPTICSPatented Gravity LED G6 optical inserts provide exceptional efficiency and light output with a Driving beam pattern and 20 watts of powerINFINITY RING/#8482; SYSTEMThe Infinity Ring/#8482; system provides a race-proven housing for the Pro6 Single that is strong; durable; and gives you a unique look for your vehicleUNIVERSAL BALL MOUNT The Pro6 Single comes ready to mount to any flat mounting surface with a highly adjustable ball mount. This universal ball mount easily attaches to many vehicles; including your Jeep; Truck or UTVRACE PROVEN STRENGTH/DURABILITY Inspired by endurance racing and tested by KC athletes worldwide; the Pro6 shatters all performance benchmarks; while providing the most durable and scalable light bar design available today

• Modular Beam Optics

The KC HiLiTES Pro6 Gravity LED Single Light is a high-output off-road lighting system designed to deliver powerful, efficient illumination for trucks, Jeeps, UTVs, and other off-road vehicles. Part KCL91303 uses a patented Gravity LED G6 optical insert and a Driving beam pattern that combines broad spread with focused distance lighting, helping improve visibility across trails, work areas, and challenging terrain.

Its patent-pending Infinity Ring™ system provides a strong, race-inspired housing for the Pro6 Single while adding a distinctive appearance. The included universal ball mount attaches to flat mounting surfaces and offers extensive adjustment for flexible positioning. A complete plug-and-play wiring harness with a 30-amp LED switch simplifies installation, while the IP68 rating supports dependable operation in demanding environments.

The KC HiLiTES Pro6 produces 2,300 raw lumens, 1,310 lux at 10 meters, and up to 131,000 candela in the spot portion of its beam. The CREE XPL HD LED source operates at 20 watts with a low 1.63-amp draw across 9-32 volts. Built with endurance-racing-inspired durability and modular Pro6 design compatibility, this lighting system provides a scalable solution for off-road lighting setups.

What's Included

• One KC HiLiTES Pro6 Single lighting system
• Universal ball mount and mounting hardware
• Complete plug-and-play wiring harness
• 30-amp LED switch

Fitment: Designed for vehicles with a suitable flat mounting surface, including Jeeps, trucks, UTVs, and other off-road applications. Verify mounting location, available electrical capacity, and vehicle-specific installation requirements before installation.

Features:

• Gravity LED G6 Optics: Patented optical inserts provide efficient, powerful light output from a compact 20-watt system.
• Driving Beam Pattern: Combines spot and spread illumination to improve trail and off-road visibility.
• Infinity Ring System: Race-inspired housing delivers durable protection and a distinctive Pro6 appearance.
• Universal Ball Mount: Highly adjustable mount supports flexible positioning on compatible flat mounting surfaces.
• High Output, Low Draw: Produces 2,300 raw lumens while drawing only 1.63 amps.
• Wide Voltage Compatibility: Operates with 9-32 volt electrical systems.
• IP68 Protection: Sealed construction helps protect internal components from dust and water intrusion.
• Plug-and-Play Installation: Includes mounting hardware, wiring harness, and a 30-amp LED switch.

Air Freight Prohibited: false
Not Carb Approved: false
Ltl Freight Required: false
Prop 65: N
Part Type: automotive
Epa: N/A
Carb Acknowledgement Required: false
Regular Stock: t
Units Per Sku: 1
