Memphis SRX300.4V

Memphis SRX300.4V

Command your vehicle's audio footprint and channel massive continuous electrical current with the street-proven performance of Memphis Audio. Famous for engineering heavy-duty car and powersports amplifiers that maximize thermal efficiency and wattage output, these powerhouses supply aggressive clean RMS headroom built to drive competitive speaker and subwoofer grids with absolute power authority.

Product Overview & Core Highlights:

Product Details:

• Class A/B 2¬†ohms Stable 4-Channel Amplifier
• RMS Power Rating:
• 4 ohms: 50¬†watts x 4¬†channel
• 2 ohms: 75¬†watts x 4¬†channel
• Bridged, 4 ohms: 150¬†watts x 2¬†channel
• Total power output: 300¬†watts
• Pulse Width Modulated MOSFET power supply
• Speaker-level (high-level) inputs
• Bridgeable & tri-mode operation
• Textured aluminum heatsink
• Ultra-bright LED accent light strip
• Selectable bass boost
• Nickel plated connectors
• 3-way protection circuitry (thermal, overload, reverse polarity, and speaker short protection)
• Input sensitivity:
• Low level: 200mV - 6.3¬†volts
• High level: 1.8mV - 25¬†volts
• Frequency Response: 10 - 24000¬†Hz
• Total Harmonic Distortion (THD): 1%
• Signal to Noise Ratio: 90¬†dB
• Variable high-pass filter: 50 - 1000¬†Hz, 12 dB/octave
• Variable low-pass filter: 50 - 250¬†Hz, 12 dB/octave
• Variable Bass Boost: Selectable 0, 6, and 12 dB @ 45 Hz bass boost at 50 Hz
• 8¬†AWG gauge power and ground wiring is recommended for installation.
• Dimensions: 12.46"¬†W¬†x 7.87"¬†L¬†x 2.16"¬†H
• Authorized Internet Dealer

🚨 Critical Performance Specifications:

• Package Quantity Configuration: Sold Individually (Includes 1 High-Output Component Unit)
• Manufacturer Part Number (MPN): SRX300.4V
• Product Category Component: Amplifiers
• Nominal Voice Coil Resistance Stability: 4 ohm
• Total Package Boxed Shipping Weight: 8.0 lbs
