Fuel your soundstage grid with raw electrical muscle and master your acoustic layout with the street-proven engineering of Rockford Fosgate power amplifiers. Renowned globally for continuous current regulation, advanced thermal heat dissipation casing networks, and signature clean signal tracking circuits, these amplifiers deliver massive output headroom with absolute zero distortion thresholds.
Product Overview & Core Highlights:
Rockford Fosgate PM500x1BD
The PM500X1bd is a 500 Watt mono amplifier with high dynamic power using Class-bd technology and a conformal coated pc board designed for motorsport and marine applications.
With its super efficient Class-bd circuit topology, the PM500X1bd will drop some serious BASS! Due to its dedicated low frequency response, this amplifier is optimized for mid-bass speakers or subwoofers only. No need to worry because its 1-ohm capability will drive a pair of 4-ohm DVC subwoofers or quad-configuration of 2-ohm DVC subwoofers with ease.
FEATURES AT A GLANCE
- High level input capable with Auto Turn-On circuit
- Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator)
- RCA pass-thru outputs
- 12dB/octave Butterworth crossover
- Features C.L.E.A.N. Set-up
- On-board Punch EQ with +18dB boost @ 45Hz
- Muted turn on
- Cast aluminum heatsink
- Stealth top mounted control panel
- Short circuit protection
- Over current protection
- Infrasonic filter
- Marine grade two part epoxy coating on circuit boards
- Marine grade stainless steel hardware
- 2-Year Warranty
🚨 Critical Performance Specifications:
- Package Quantity Configuration: Sold Individually (Includes 1 High-Performance Component Unit)
- Manufacturer Part Number (MPN): PM500x1BD
- Product Category Component: Amplifiers
- Total Package Boxed Shipping Weight: 10.8 lbs
