Hertz VENEZIA V5 1660W Class D 5-Channel Marine Amplifier

Hertz VENEZIA V5 1660W Class D 5-Channel Marine Amplifier

Hertz -

Regular price $1,299.99 USD
Regular price $1,485.00 USD Sale price $1,299.99 USD
Sale Special Order this item by Clicking the Chat Button Below
Shipping calculated at checkout.

VENEZIA V5 is the most-powerful five-channel Hertz marine amplifier ever, featuring 130 W x 4 (4Ω) plus 470 W (4Ω) for the subwoofer! Hertz Advanced Class D technology maximizes efficiency and power while minimizing heat and electromagnetic radiation - enhancing sound quality that reaches new highs with Hi-Res certification! High-powered channels with bridging capability deliver the output levels needed in the marine environment. Venezia V5 is engineered and tested for marine applications (UV, salt-fog, vibrations, high/low temperature, thermal shock) and has obtained the IPX2 certification. The Safe-Lock Input, Output, and Power connections streamline installation and enhance durability in the field. The fanless convection cooling system is integrated into the cast heat-sink chassis. The balanced fully-differential input circuitry rejects electromagnetic noise and interference. The powerful and flexible preamp filter options are far beyond most mobile amplifier capabilities. Last but not least, Venezia V5 is fully protected by short-circuit, overload, and thermal protections with auto-resetting.

Channels 5 - 3
POWER SUPPLY
Power supply voltage 9 ÷ 16 VDC
ldling current (power ON/OFF): 1.8 A / 0.04 mA
Consumption@ 1Ω, 14.4 VDC (Max Musical Power): 70 A
Remote In: 7 ÷ 15 VDC - 1 mA
AMPLIFIER STAGE
Distorsion - THD (100Hz @ 4Ω): <0,05%
Bandwidth: 10 ÷ 42 kHz
S/N Ratlo (A welghted @ 1 V): 102 dB
Damping factor (100Hz @ 4Ω) 130
Pre-ln sensitivity: 0.2 ÷ 5 VRMS
Pre-ln impedance: 10 kΩ
Load impedance (MIN)
@5Ch:
@3Ch:


4Ω + 4Ω + 2Ω
Weight (kg/lb): 3.72 / 8.2
Adjustable Crossovers yes
Output Power
OUTPUT POWER (RMS) @ 14.4 VDC, THD 1%
5Ch 130 W x 4 (4Ω) + 490 x 1 (4Ω)
5Ch 220 W x 4 (2Ω) + 820 W x 1 (2Ω)
3Ch 440 W x 2 (4Ω) + 490 W x 1 (4Ω)
3Ch 440 W x 2 (4Ω) + 820 W x 1 (2Ω)
Total Power 1700 W
